Acoustic Partitions

Complete Specification Guide: Acoustic Partitions

Acoustic partitions are critical for dynamic space management in corporate, hospitality, and institutional environments. Our movable acoustic partitions deliver exceptional sound transmission loss while allowing rapid reconfiguration of large spaces.

Engineering & Performance:

The supplied W Type movable partition profile documents laboratory acoustic performance around STC 55-56 dB, with nominal 100 mm thick panels and single seamless panels available up to 18 meters high. The system uses 2 mm welded heavy-duty galvanized steel frames, acoustic infill, galvanized steel faces, and tongue-and-groove vertical seals to prevent panel-to-panel sound leaks.

Track and Carriage Systems:

A partition is only as good as its mobility and seal. The verified profile uses top-supported track systems in architectural-grade aluminum alloy 6063-T6, with optional steel track where height or weight exceeds aluminum track limits. Dual-wheel carriers with precision-ground bearings allow panels to negotiate 90-degree turns, X, L, and T intersections for flexible parking layouts.

Acoustic Sealing Mechanisms:

To achieve laboratory-rated STC performance in the field, the system uses four-finger sweep seals, top and bottom retractable seals, and crank-down mechanical operation by removable handle. The profile documents 25 mm nominal top operating clearance and 38 mm nominal bottom clearance to accommodate normal floor gradient, with final closure panels using an expandable jamb to tighten the partition for optimum acoustics.

Maintenance and Finish Options:

Finish options verified from the supplied PDFs include MDF, steel face, carpet fabric, wood veneer, laminate, canvas, tapestry or fabric, and other custom finishes. Unfinished panels can also be supplied for field-applied finishes.
